Locor Deluxejet 6ft 1.8m Eco Solvent Large Format Printer with three 4720 heads

date :2017-8-18 0:13:16hits :6070author:郑州乐彩


Product Description

Locor Deluxejet 1830 large format printer is our new developed model. It has become a hot-sale since come out. This inkjet printer can be used for not only outdoor eco solvent printing, indoor water-based printing, but also sublimation printing, as well as UV roll to roll printing. With three Epson 4720 heads, it realizes high quality print as well as faster speed. DX7 head optional. Classical printer body design, high quality parts and professional color CISS to satisfy different clients' need.


Technical Parameters


Deluxejet 1830


Print head

4720 * 3

Print resolution

720*1200dpi, 720*1800dpi

Print head height


Print head cleaning

Automatic cleaning, with anti-blocking flash spray and automatic moisturizing function

Print Speed

Draft mode


Production mode


Precision mode


Ink Supply

Ink type

Eco solvent ink, sublimation ink, water-based ink

Ink color


Ink tank volume


Ink supply system

Negative pressure CISS continuous ink supply


Print width


Media type

Flex banner, sticker, PP paper, one way vision, reflective film, wall paper, sublimation paper, etc

Max Load


Take-up and Platform



Heating system

Front, middle and back, three-stage embedded constant temperature synchronous heating control system

External dryer

External infrared heating and drying fans

Operation System


English and Chinese

PC system

Win 7  32bit/64bit


Temperature: 18-25°C, Humidity: 35-65% Rh

Printing System

Print port

1000M /Network port

Rip software

Maintop / Photoprint / Wasatch

Power Supply


AC-220V ±10%,50Hz/60Hz


Standby 64w, Max 5500W

Size and Weight

Machine size and weight

3106*924*1620mm (L*W*H)  278kg

Package size and weight

3194*1140*814mm (L*W*H)  318kg


  Zhengzhou Locor Technology Co., Ltd. has a registered capital of 26 million RMB. The company has a young, efficient, united and innovative elite team, and an entrepreneurial environment that catches up with the international advanced level, leads the development of the Chinese industry.

 Locor pays attention to the research and application development of independent technology in the field of printing equipment,has established a company technology research and development center, equipped with advanced equipment and testing instruments with a good R&D experimental environment. The company's technical department cooperates with many research institutes at home and abroad, uses the current new micro-electromechanical and micro-electronic technology to conduct exploratory research and development. It is used in printer print head drive analysis, rack manufacturing, testing, control system design, trial production, etc. Unique insights and innovative inventions.

    Locor has applied for 51 patents related to digital printing equipment, including 3 invention patents; in 2008, the company was recognized as a high-tech enterprise by Henan Science and Technology Department, has passed the EU CE certification in 2008; in May 2010, Zhengzhou Development and Reform Commission Approved the establishment of Zhengzhou Digital Wide-format Printing Equipment Engineering Research Center and listed it in the National Twelfth Five-Year Plan for Electronic Information Industry; In June 2010, it officially started the shareholding system reform and became the first batch of new three-board enterprises in Zhengzhou High-tech Industrial Development Zone.

At present, Locorproducts and service organizations have covered more than 80 countries and regions in 31 provinces and cities in China and overseas; Locor are willing to work together with friends in the industry to provide satisfactory products and services for domestic and foreign customers!
